316L Stainless Steel Pipe
🔥 Stop risking catastrophic chloride pitting, rapid structural degradation, or severe project-site inspection rejections due to unverified material chemistry or counterfeit alloy mill runs.
SXY Steel Group manufactures industrial-grade, molybdenum-enriched 316L marine stainless steel pipes (available in heavy-wall seamless and precision automatic-welded configurations) engineered specifically to withstand aggressive salt-water, coastal atmospheric corrosion, and harsh chemical fluid environments. Fabricated with a strict low-carbon threshold (C≤0.03%) and verified molybdenum content (2.0-3.0%) to completely eliminate intergranular sensitization during field welding, our premium 316L piping provides supreme mechanical yield reliability and localized corrosion defense under extreme operational stresses. Secure your prioritized container mill capacity today via our Guaranteed 2-Hour Rapid Quote service before raw material alloy indices fluctuate.
Tired of slow emails while your marine infrastructure or chemical processing project deadline is closing in? Eliminate site submittal failure anxieties and secure your verified molybdenum-grade testing records right now.
PRODUCT DETAILS
📊 Austenitic Marine Stainless Steel Three-Standard Cross Matrix
| American Standard (ASTM) | European Standard (EN) | Japanese Standard (JIS) | Chinese Standard (GB) | Core Material Performance Profile |
|---|---|---|---|---|
| ASTM A312 / A249 TP316L (UNS S31603) | EN 10217-7 / 10216-5 1.4404 | JIS G3459 SUS316L | GB/T 14976 022Cr17Ni12Mo2 | Mo≥2.0%, C≤0.03% Ultra-Low Carbon, Elite Anti-Pitting In Severe Chloride/Saline Marine & Aggressive Acid Handling Systems |
| ASTM A312 TP316 (UNS S31600) | EN 10217-7 1.4401 | JIS G3459 SUS316 | GB/T 14976 06Cr17Ni12Mo2 | Standard Molybdenum Alloy, Premium Chemical Storage, Food Processing Lines, Elevated Thermal Creep Environments |
| ASTM A312 TP304L (UNS S30403) | EN 10217-7 1.4307 | JIS G3459 SUS304L | GB/T 14976 022Cr19Ni10 | General Corrosive Media, High-Weldability Framing, Urban Infrastructure fluid pipelines without Molybdenum tracking |
• Traceable EN 10204 3.1 Certification: Dispatched with authentic Mill Test Certificates (MTC) detailing complete Intergranular Corrosion tests (ASTM A262 Practice E), flattening limits, and hydrostatic leak thresholds. Full verification support for SGS, Lloyd’s Register, and Bureau Veritas inspection agents.
• Zero-Risk Commercial Protection: SXY Steel Group eliminates international trade risk entirely for procurement departments by executing major volume engineering supply contracts via 100% Irrevocable Letters of Credit (L/C) at sight.
• Seaworthy High-Tensile Bundling: Tubes are packed firmly in rigid timber crates or structured with thick steel banding lines integrated with pre-set heavy nylon lifting slings for effortless crane discharging at destination terminals.
• Pre-Arranged Port Protection: SXY Steel Group pre-clears 14 to 21 days of complimentary container demurrage directly with leading global ocean carriers to keep your site fabrication operations completely insulated from harbor customs bottlenecks.
| Category | Details |
|---|---|
| Standard | Food Grade Sanitary Tube: JIS G3447, KS D 3585, ASTM A270, EN 10357(DIN 11850), AS 1528.1, ISO 2037(NF A49-249) Heat exchanger tube: ASTM A249 / ASME SA249, GB / T 24593-2009, HG 20537.2 Industrial pipe: ASTM A312, EN 10217-7, GB / T 12771-2008, HG 20537.3 Drinking water tube: GB / T 19228 Mechanical tube: ASTM A554, EN 10296-2 |
| Size | Outer Diameter Range: 9.5~2000mm Thickness Range: 0.5~20mm (Size can be customized.) Length: Up to 18.3 meters per piece. |
| Shape Section | Round, square, rectangular |
| Usage | Sanitary tubing: for food processing industry, beverage industry, sugar mill and so on; Heat exchanger tube: condenser, boiler, super heater, evaporator and so on; Industrial pipe: for petroleum delivery, gas delivery, petrochemical industry, wastewater treatment, drainage system, and so on; Mechanical tube: handrail, railings, balustrade, hence and so on. |
Features:
1.Our stainless steel tubes pipes are treated by bright annealing, inside weld bead removing, precise polishing. The roughness of tubes could be under 0.3μm.
2.We have the non destructive testing ( NDT ), eg. online eddy current inspection and hydraulic or airtightness testing.
3. Thick welding, good appearance.The mechanical properties of tube could be tested.
4. The raw material is from Taigang, Baogang, Zhangpu and so on.
5. And Our tubes are certificated by AD 2000-W0, PED 2014/68/EU, ISO 9001 : 2015.
6. Full material traceability is guaranteed during the manufacturing process.
7. Polished tube is supplied in individual plastic sleeves with capped ends ensuring optimum cleanliness.
8. Internal Bore: Tubes have a smooth, clean and crevice free bore.
Packing and shipping
Our company has passed ISO9001 quality management system certification, Our Mill product with CE/EN10204 / ASTM/Classification society certificate/CASO/BIS etc certificate.All the customers give good appreciation to our products.We are glad to be your good partner.
Application Areas
Steel is widely used in steel structure workshops, bridge frames, main structures of high-rise buildings, and infrastructure construction (such as highways, oil and gas pipelines). Its high strength properties ensure load-bearing stability and seismic performance. In ship manufacturing, steel is used to build hull structures, decks, and internal components. Hot-rolled coils rely on their load-bearing capacity to adapt to harsh environments.
Factory workshop
With a commitment to excellence, innovation, and sustainability, the company has established itself as a trusted partner in the international steel industry.After nearly two decades of relentless endeavour, our client base now spans over 110 countries and regions across Europe, the Middle East, South America, and Southeast Asia.
🔬 Free Project Bill of Materials (BOM) Nesting Calculation & Linear Allocation Analysis
Submitting formal engineering blueprints for marine pipelines, offshore platforms, coastal fluid handling arrays, or heavy chemical refinery installations? Paste your raw technical files, industrial spool drawings, or itemized Bill of Materials (BOM) grids into the contact form below. The industrial engineering team at SXY Steel Group will perform a programmatic nesting computation to optimize pipeline cuts, eliminate high-cost material scrap, and protect your project procurement capital.
