2024-T3 Aluminum Foil
Procure high-strength 2024-T3 aluminum foil, engineered for superior fatigue resistance, excellent fracture toughness, and precise gauge control required for aerospace skinning, structural laminates, and high-performance industrial bonding. Our factory guarantees strict T3 temper conformity, precise dimensional tolerances, and full mill-test traceability—delivered with 2-hour rapid technical quotes.
Tired of material inconsistencies or gauge variations stalling your aerospace fabrication project? Terrified of buying sub-standard foil that leads to critical fatigue failure or project-wide rejections? Stop the gamble—secure certified, high-strength 2024-T3 aluminum foil from our factory right now.
PRODUCT DETAILS
2024-T3 Aluminum Foil Three-Standard Cross Matrix
| US Standard (ASTM) | Euro Standard (EN) | China (GB) | Temper | Gauge Range |
|---|---|---|---|---|
| ASTM B479 2024 | EN 546 2024 | GB/T 3198 2024 | T4 | 0.006 – 0.2mm |
| ASTM B479 2024 (Target) | EN 546 2024 | GB/T 3198 2024 | T3 | 0.01 – 0.5mm |
Technical QA/QC Verification
• Certification & Security: We provide EN 10204 3.1 MTCs with every shipment. To eliminate capital risk, our factory supports 100% Irrevocable Letters of Credit (L/C) at sight. We are ready for pre-shipment inspections by SGS, Bureau Veritas, or Intertek.
Logistics & Export Handling
• Port Efficiency Buffer: Our factory negotiates up to 21 days of extended free container demurrage on your Bill of Lading, protecting local clearing agents from costly administrative delays.
About the aluminum
The mechanical properties of 2024-T3 aluminum alloy can be significantly improved after heat treatment. 2024 is a typical duralumin alloy in the aluminum-copper-magnesium system. It is a heat-treatable alloy with high strength, easy to work, easy to turn, and moderate corrosion resistance. Main applications: aircraft structure, rivets, truck wheels, propeller components and other structural parts. 2024 aluminum alloy is a kind of high strength duralumin, which can be strengthened by heat treatment. It has medium plasticity under quenching and quenching state, good spot welding and gas welding, and has a tendency to form intercrystalline cracks. The alloy has good machinability after quenching and cold work hardening, and low machinability after annealing. Corrosion resistance is not high, often using anodic oxidation treatment and paint method or surface coated aluminum layer to improve its corrosion resistance. It is mainly used for making various high-load parts and components (but not including stamping parts and forgings), such as skeleton parts, skin, frame, wing ribs, wing beams, rivets and other working parts below 150℃.
Chemical composition: Silicon Si: 0.50; Cu: 3.8-4.9; Mn: 0.30-1.0; Magnesium Mg: 1.2-1.8; Chromium Cr: 0.10; Zinc Zn: 0.25; Aluminum Al: allowance;
2024 aluminum alloy, the main alloying elements are copper and magnesium. Applications where high strength but low weight ratio is required, and good fatigue strength. Not weldable, general processing performance. Because of poor corrosion resistance, aluminum-zinc splints are often used as protection, which results in reduced fatigue strength.
2025-T3 aluminum alloy has ultimate tensile strength of 58,000-62,000 psi (400-427 MPa) and yield strength of 39,000-40,000 psi (269-276 MPa). Elongation 10-15%.
Aluminum is a silver-white light metal, relatively soft, density 2.7g/cm3, melting point 660.4℃, boiling point 2467℃, aluminum and aluminum alloys have many excellent physical properties, has been very widely used. Aluminum has good reflection performance of light, reflecting ultraviolet light is stronger than silver, the purer aluminum is, its reflection ability is better, and the method of vacuum aluminum plating is commonly used to make high-quality mirrors. Vacuum aluminized film combined with polysilicon film becomes a cheap and lightweight solar cell material. Aluminum powder can maintain a silvery luster, often used to make paint, commonly known as silver powder. Pure aluminum conducts electricity very well, second only to silver and copper. In the electric power industry, it can replace part of copper for wires and cables. Aluminum is a good conductor of heat. It can be used to make various heat exchangers, heat dissipating materials and civil cookers in industry. Aluminum has good ductility, can be drawn into a fine wire, rolled into a variety of aluminum products, but also can be made into thinner than 0.01mm aluminum foil, widely used in packaging cigarettes, candy, etc.. Aluminum alloy has some better properties than pure aluminum, which greatly expands the application range of aluminum. For example, pure aluminum is soft, when a certain amount of copper, magnesium, manganese and other metals are added to aluminum, the strength can be greatly improved, almost equivalent to steel, and the density is small, not easy to rust, widely used in aircraft, cars, trains, ships, artificial satellites, rockets manufacturing. At -196 ° C, some steel is as brittle as glass, while some aluminum alloys increase in strength and toughness, making them cheap and lightweight cryogenic materials that can be used to store liquid oxygen and hydrogen for rocket fuel.
PRODUCT
Aluminum Foil Specifications
| Standard | ASTM, GB, JIS, AISI, EN |
| Thickness | 0.006mm (6micron) – 0.2mm (200micron) |
| Width | 120-1500 mm (tolerance: ±1.0mm) |
| Temper | O, F, H12, 114, H18, H22, H24, H26, H32, etc. |
| Application | Aluminum foil is widely used in food, beverage, cigarette, medicine, photographic plate, household articles, etc. It is usually used as its packaging material, electrolytic capacitor materials, insulation materials for buildings, vehicles, ships and houses. |
| Price Term | Ex-work, FOB, CFR, CIF, etc. |
| Delivery Time | 20-30 days. Standard size is in stock, prompt delivery or as order’s quantity. |
| Package | Export standard package, Carton box or wooden case, or waterproof paper, or as customer’s request. The inner size of container is below: |
Aluminum Production Process
Packing and shipping
Our company has passed ISO9001 quality management system certification, Our Mill product with CE/EN10204 / ASTM/Classification society certificate/CASO/BIS etc certificate.All the customers give good appreciation to our products.We are glad to be your good partner.
Application Areas
Steel is widely used in steel structure workshops, bridge frames, main structures of high-rise buildings, and infrastructure construction (such as highways, oil and gas pipelines). Its high strength properties ensure load-bearing stability and seismic performance. In ship manufacturing, steel is used to build hull structures, decks, and internal components. Hot-rolled coils rely on their load-bearing capacity to adapt to harsh environments.
Factory workshop
With a commitment to excellence, innovation, and sustainability, the company has established itself as a trusted partner in the international steel industry.After nearly two decades of relentless endeavour, our client base now spans over 110 countries and regions across Europe, the Middle East, South America, and Southeast Asia.
Free Technical Fabrication & Compatibility Audit
Scaling your aerospace or high-performance industrial capacity? Send us your technical drawings or project BOM requirements. Our engineers will perform a free compatibility analysis to ensure the alloy temper and gauge perfectly match your stamping, forming, or laminating requirements.
